Newly developed Six shuttle High Speed Circular Loom suitable for all different types of packaging applications & only loom having maximum meter age production capabilities, having maximum tubular width of 900 mm.
| MODEL NO :- EM 490 |
||
| Description:- | Model No. 490 |
|
| Working width Double flat:- |
( Min. / Max.) |
300 / 850 mm |
| Shuttles:- | 4 | |
| Tube Diameter |
35 mm |
|
| Tube Length |
218 mm |
|
| Bobbin Diameter |
110 mm |
|
| Traverse Length |
200 mm |
|
| Warp Bobbin:- |
Tube Diameter |
35 mm |
| Tube Length |
218 mm |
|
| Bobbin Diameter |
130 mm |
|
| Traverse Length |
200 mm |
|
| Creel Capacity:- |
Bobbin / Machine |
720 |
| Fabric Surface Winder |
1020 mm |
|
| Picks / Minute:- |
( Min./Max.) |
640 / 720 |
| R.P.M.:- | ( Min./Max.) |
160 / 180 |
| Web Density:- |
22-75/10 cm |
|
| Requirement of space:- |
Length | 9170 mm |
| Width | 2760 mm |
|
| Height | 2935 mm |
|
| Electrical:- | Phase/Vol/hz | 3 / 415 / 50 |
| Main Motor |
3.7 KW |
|
| Winder Motor |
0.37 KW |
|
